HeartSave myPAD 670A AED (Fully Automatic, No Display)
Primedic
Contact for price
Fully automatic version of the HeartSave myPAD with LED indicators only (no screen); the shock is delivered automatically without the rescuer pressing a button. Weight approx. 1.0 kg, 151 x 151 x 73 mm. Compact AED (151 x 151 mm) with biphasic truncated exponential (BTE) waveform auto-compensated to patient impedance, delivering 150/170/200 J for adults and 50 J in child mode via the child button. IP66 dust- and waterproof, 1.6 m drop-tested, operating from 0 to 55 °C, with 8 GB memory, up to 6 selectable languages and ERC-2025 guidelines. Uses pre-connectable electrodes (5-year shelf life) and a 5-year LiMnO2 battery (12 V / 2.8 Ah, 130 shocks at 200 J) or an optional 12-year rechargeable Li-ion battery (230 shocks at 200 J); optional CPR-feedback sensor and LTE / WiFi IoT connectivity. 8-year warranty.
- Weight
- approx. 1.0 kg
- Dimensions
- 151 x 151 x 73 mm
- Waveform
- biphasic truncated exponential (BTE)
- Energy Output Adults
- 150/170/200 J
- Energy Output Child
- 50 J
- IP Rating
- IP66
- Drop Test
- 1.6 m
- Operating Temperature
- 0 to 55 °C
- Memory
- 8 GB
- Languages
- up to 6 selectable languages
- Guidelines
- ERC-2025
- Electrode Shelf Life
- 5-year
- Battery Shelf Life
- 5-year
- Battery Specs
- LiMnO2 battery (12 V / 2.8 Ah, 130 shocks at 200 J)
- Optional Battery Specs
- 12-year rechargeable Li-ion battery (230 shocks at 200 J)
- Warranty
- 8-year
