TOPAZ-40D Mobile X-ray System

TOPAZ-40D is the 40 kW version of DRGEM's TOPAZ motorized mobile digital X-ray system for bedside imaging of patients who cannot be moved to radiology, such as in ICUs and wards. It gives 40 to 125 kV (150 kV option), up to 500 mA and 0.1 to 500 mAs, with a CsI flat panel detector (wired or wireless 10x12, 14x17 and 17x17 inch) and RADMAX software on a 21.5 inch touch screen. The column rotates up to 330 degrees each way and comes collapsible (clear forward view while driving) or non-collapsible; it climbs inclines up to 10 degrees and has a live camera of the collimated field, a software grid and tablet Smart Control.

Power

40 kW

Tube Voltage

40 to 125 kV (150 kV option)

Tube Current

up to 500 mA

mAs Range

0.1 to 500 mAs

Detector Type

CsI flat panel detector (wired or wireless 10x12, 14x17 and 17x17 inch)

Display Screen

21.5 inch touch screen

Column Rotation

up to 330 degrees each way

Maximum Incline

up to 10 degrees
