GXR-U32S Diagnostic X-ray System

GXR-U32S is a stationary analog diagnostic X-ray system of DRGEM's GXR-S Series for general radiography, built around a battery-powered high-frequency generator rated 32 kW that is recharged from a small line supply and delivers the same output as line-powered units. The DRGEM-made generator and tube give 40 to 125 kVp (150 kVp option) with automatic calibration, and the system is supplied as floor mounted, floor-ceiling suspended, premium floor mounted or premium ceiling configurations. It is the analog (cassette-based) version and can be upgraded to digital radiography with DRGEM's AcquiDR flat panel kit; options include AEC, DAP meter, motorized vertical synchronization and table Bucky auto tracking. It suits hospitals, clinics and mobile X-ray vans.

Generator Power

32 kW

Generator Type

High-frequency generator, battery-powered

Series

DRGEM GXR-S

Components

Generator, tube stand, patient table, wall stand
