JADE-40 Mobile X-ray System

JADE-40 is the 4 kW version of DRGEM's JADE lightweight mobile and portable X-ray unit for bedside, ward, operating room, home-care and veterinary imaging. Its high-frequency generator covers 40 to 120 kV in 1 kV steps, 10 to 100 mA and 0.1 to 250 mAs, and the X-ray head with collimator weighs 16.8 kg. It mounts on the JMS mobile stand or the foldable JPS-1 and tabletop JPS-2 portable stands, and can be operated from its own panel, an external panel, a remote control or an app over USB or Bluetooth, with up to 9 user APR presets. A DR option adds a flat panel detector, laptop and imaging software. It is not intended for mammography, bone density or dedicated pediatric use.

Power

4 kW

Generator voltage range

40 to 120 kV in 1 kV steps

Generator current range

10 to 100 mA

Generator mAs range

0.1 to 250 mAs

X-ray head with collimator weight

16.8 kg

Connectivity

USB or Bluetooth

User APR presets

up to 9
