RAYMO Mobile X-ray System

RAYMO is DRGEM's compact motorized mobile digital X-ray system for bedside imaging of patients who cannot be moved to radiology, with about 20 percent less volume than earlier mobile systems. Its 40 kW generator gives 40 to 125 kV (150 kV option), up to 500 mA and 0.1 to 500 mAs, and the column rotates up to 330 degrees each way. Haptic feedback near the target SID, parking unlock assist, a tilting touch screen on the tube, a day/night driving camera and an anti-theft detector tray aid daily use, while RFID user recognition recalls each operator's monitor angle, handlebar position and driving sensitivity. A tablet Smart Control allows remote operation.

Generator power

40 kW

Tube voltage (kV)

40 to 125 kV (150 kV option)

Current (mA)

up to 500 mA

mAs range

0.1 to 500 mAs

Column rotation

up to 330 degrees each way
