DIAMOND-6A U-arm Digital X-ray System

DIAMOND-6A is DRGEM's fully automatic U-arm digital X-ray system for general radiography, fitted with the 68 kW GXR-68 high-frequency generator. The motorized U-arm with four joints moves to pre-programmed positions, covers SID from 100 to 180 cm and works with a mobile patient table for more than 15 patient positions. A CsI flat panel detector, motorized collimation that follows the SID, a 3-field AEC ion chamber, automatic stitching and RADMAX image processing are included, controlled from a touch console or remote control. It is not intended for mammography, bone density, fluoroscopy or angiography.

Generator

68 kW DRGEM GXR

U-arm Rotation

+120 to -30 degrees

SID

100 to 180 cm

Detector

CsI flat-panel

AEC Chamber

3-field

Patient Table

Mobile with over 15 positions
