5T Pro Dental Milling Machine

Multifunctional five-axis composite dental milling machine for zirconia, wax, glass ceramic, preformed titanium posts, PMMA and PEEK, used for crowns, bridges, long bridges, bridge frames and other precision restorations. It has a 3.7 kW electric spindle up to 40,000 rpm, a 15-tool magazine with ISO20/ER16 tool holding, B-axis +/-30 degrees and A-axis 0-360 degrees, repeatability of +/-0.003 mm, automatic tool setting, a tool life management system, spindle water cooling and oil-mist recovery. It runs on three-phase 380 V and weighs about 1.3 tons.

electric spindle power

3.7 kW

maximum spindle speed

40,000 rpm

tool magazine capacity

15-tool

tool holding

ISO20/ER16

B-axis range

+/-30 degrees

A-axis range

0-360 degrees

repeatability

+/-0.003 mm

power supply

three-phase 380 V

weight

about 1.3 tons
