5M Pro Dental Wet Milling Machine

Five-axis wet-cutting dental milling machine that keeps the five-axis linkage of earlier models and adds spindle power for steadier grinding of glass ceramics and titanium abutment columns. It has a 1.8 kW high-frequency spindle, AC servo drives, a ball-screw drive, positioning accuracy of 0.01 mm and repeat accuracy of 0.005 mm, A-axis rotation of +/-360 degrees and B-axis +/-30 degrees. It records tool service life in real time, processes at 90 degrees vertical and offers two switchable color themes. Dimensions are 580 x 700 x 755 mm and weight is 160 kg.

Spindle Power

1.8 kW

Positioning Accuracy

0.01 mm

Repeat Accuracy

0.005 mm

A-axis Rotation

+/-360 degrees

B-axis Rotation

+/-30 degrees

Dimensions

580 x 700 x 755 mm

Weight

160 kg
