NewOn order
GSL5M Dental Wet Milling Machine
Glorious dental
Contact for price
Five-axis linkage wet-cutting dental milling machine for premill abutments, lithium disilicate, elastic ceramic and amber ceramic, with a stated five-axis error below 0.02 mm for fine undercut machining. It has a 60,000 rpm wet, water-cooled spindle, an 8-tool magazine, HIWIN ball screws and guide rails, repeatability of +/-0.005 mm, A-axis 360 degrees, and runs on AC 220 V. It can mill several premill abutments or glass-ceramic blanks in one run, records tool life in real time and weighs about 150 kg.
- Axes
- Five-axis linkage
- Five-axis error
- below 0.02 mm
- Spindle speed
- 60,000 rpm
- Spindle type
- wet, water-cooled
- Tool magazine capacity
- 8-tool
- Ball screws and guide rails
- HIWIN
- Repeatability
- +/-0.005 mm
- A-axis range
- 360 degrees
- Voltage
- AC 220 V
- Weight
- about 150 kg
